Specially designed cutting teeth realize efficient removal of dust.
The carbide-tipped teeth allow drilling in work materials such as stainless steel.
Our original design of the cutting teeth permits smooth removal of dust from the hole.
Deep bore of body allows even pipes or curved surfaces to be drilled.
For making a hole in steel plates, stainless steel plates, cast iron plates, etc. of up to 30mm (1-3/16") thickness. ( We recommend the use of a drill press before cutting steel plates, stainless steel plates, cast iron plates,
etc. of 12mm (15/32") or larger in thickness and also before making a hole with a cutter which has a diameter of 36mm (1-13/32") or larger. )
A cutter capable of drilling curved surfaces such as metal pipes, due to deep bore of its body.
Composite materials of up to 30mm (1-3/16") thickness.
o14mm to 120mm (o35/64" to 4-3/4")
Max. drilling depth:
Click here for the size table of the Poly-Clic shanks.
Applicable electric drill: Portable electric drills (in the rotary-only mode) or various drill presses
