Deltagon bits SDS-plus
![Characteristics](img/tit_no39_44_01.gif)
- Higher cutting performance for reinforcing bars.
- Drilling through deck plates.
- Drilling holes close to a perfect roundness.
- More accurate hole starting without bit walk.
- Triple thread is used. (the delta-shank types are used for drill bits with a small diameter.)
- Limited circumferential wear.
- The least amount of vibration when drilling minimizes workers' fatigue.
![Applications](img/tit_no39_44_02.gif)
- Concrete, block, mortar, stone, brick, concrete-placed deck plate, etc.
![Specifications](img/tit_no39_44_03.gif)
![](../../img/mark_nakaguro.gif) |
Bit diameter: |
o 3.2mm to 22.5mm |
![](../../img/mark_nakaguro.gif) |
Overall length: |
See size table. |
![](../../img/mark_nakaguro.gif) |
Max. drilling depth: |
![](../../img/mark_nakaguro.gif) |
Applicable electric drill: |
Light-weight hammer drills |
![](img/img_no40_02.gif)
![Size Table](../img/btn_size.gif)
Deltagon bits SDS-plus (Spiral type)
![Characteristics](img/tit_no39_44_01.gif)
- Power of cordless hammer drill; thread shape suitable for rotation rate.
- The same characteristics as the general Deltagon bit SDS-plus except for the thread shape.
![Applications](img/tit_no39_44_02.gif)
- Concrete, block, mortar, stone, brick, concrete-placed deck plate.
![Specifications](img/tit_no39_44_03.gif)
![](../../img/mark_nakaguro.gif) |
Bit diameter: |
o 3.2mm to 6.0mm |
![](../../img/mark_nakaguro.gif) |
Overall length: |
See size table. |
![](../../img/mark_nakaguro.gif) |
Max. drilling depth: |
![](../../img/mark_nakaguro.gif) |
Applicable electric drill: |
Cordless hammer drill |
![Size Table](../img/btn_size.gif)
